MAX6675 Thermocouple Temperature over Wi-Fi with ESP8266 NodeMCU D1 Mini
In this tutorial, we learn how to use a MAX6674 K-type thermocouple sensor with an ESP8266 NodeMCU and D1 Mini to measure temperature over WiFi on a desktop, tablet, and mobile phone. The code can use Ajax, which requires your router to be connected to WiFi, and without Ajax, which does not require WiFi.
图像
Browser screen on Desktop
Browser screen on Desktop
Browser screen on Mobile Phone
Browser screen on MObile Phone
340-MAX6675 Thermocouple Temperature over WiFi with ESP8266 NodeMCU D1 Mini
语言: C++
/*
*
* This is Arduino code to measure a MAX6675 K-Type thermocouple sensor
* over Wifi using an ESP8266 NodeMCU and D1 Mini.
* This code can work with and without Ajax. See the video for details.
*
* Watch the video instruction for this code: https://youtu.be/sS5apP9vqak
*
* Full explanation of this code and wiring diagram is available at
* my Arduino Course at Udemy.com here: http://robojax.com/L/?id=62
* Written by Ahmad Shamshiri on July 06, 2020 in Ajax, Ontario, Canada
* www.robojax.com
*
* Get this code and other Arduino codes from Robojax.com.
Learn Arduino step by step in a structured course with all materials, wiring diagrams and libraries
all in one place.
If you found this tutorial helpful, please support me so I can continue creating
content like this.
or make a donation using PayPal http://robojax.com/L/?id=64
Related videos:
Introduction to MAX6675 K-Type: https://youtu.be/VGqONmUinqA
Using MAX6675 K-Type thermocouple with an LED display: https://youtu.be/cD5oOu4N_AE
Using MAX6675 K-Type thermocouple with an LCD1602-I2C: https://youtu.be/BlhpktgPdKs
Using 2 or more MAX6675 K-Type thermocouples: https://youtu.be/c90NszbNG8c
Using MAX6675 K-Type thermocouple as a heater or cooler controller: [this video]
* * This code is "AS IS" without warranty or liability. Free to be used as long as you keep this note intact.*
* This code has been downloaded from Robojax.com
This program is free software: you can redistribute it and/or modify
it under the terms of the GNU General Public License as published by
the Free Software Foundation, either version 3 of the License, or
(at your option) any later version.
This program is distributed in the hope that it will be useful,
but WITHOUT ANY WARRANTY; without even the implied warranty of
MERCHANTABILITY or FITNESS FOR A PARTICULAR PURPOSE. See the
GNU General Public License for more details.
You should have received a copy of the GNU General Public License
along with this program. If not, see <https://www.gnu.org/licenses/>.
*/
//Watch the video for details of the lines below
static const uint8_t D0 = 16;
static const uint8_t D1 = 5;
static const uint8_t D2 = 4;
static const uint8_t D3 = 0;
static const uint8_t D4 = 2;
static const uint8_t D5 = 14;
static const uint8_t D6 = 12;
static const uint8_t D7 = 13;
static const uint8_t D8 = 15;
static const uint8_t D9 = 3;
static const uint8_t D10 = 1;
///////// Start of MAX6675 settings
#include "max6675.h"
//Robojax.com MAX6675 Thermocouple
int thermoCLK = D4;
int thermoCS = D3;
int thermoDO = D2;
MAX6675 thermocouple(thermoCLK, thermoCS, thermoDO);
float tempC, tempF, tempK;
char type='C';//default temperature type C
char *titleMain="Using ESP8266";
char *titleTemp="Temperature: ";
int refreshTime =5000;
const bool useAjax=false;//set to "true" or "false". if set to "true" then internet connection is needed
/////////////// end of MAX6675 settings
#include <ESP8266WiFi.h>
#include <WiFiClient.h>
#include <ESP8266WebServer.h>
#include <ESP8266mDNS.h>
#ifndef STASSID
#define STASSID "Robojax"//your Wifi SSID (case sensitive)
#define STAPSK "YouTube2020"//your WiFi password
#endif
const char *ssid = STASSID;
const char *password = STAPSK;
ESP8266WebServer server(80);
void handleRoot() {
//Robojax.com MLX90614 with ESP8622 with Ajax
String HTML ="<!DOCTYPE html>\
<html>\
<head>\
\t\n<title>Robojax MAX6675 Thermocouple</title>\
\t\n<meta name=\"viewport\" content=\"width=device-width, initial-scale=1\">\
\n<style>\
\nhtml,body{\t\nwidth:100%\;\nheight:100%\;\nmargin:0}\n*{box-sizing:border-box}\n.colorAll{\n\tbackground-color:#90ee90}\n.colorBtn{\n\tbackground-color:#add8e6}\n.angleButtdon,a{\n\tfont-size:30px\;\nborder:1px solid #ccc\;\ndisplay:table-caption\;\npadding:7px 10px\;\ntext-decoration:none\;\ncursor:pointer\;\npadding:5px 6px 7px 10px}a{\n\tdisplay:block}\n.btn{\n\tmargin:5px\;\nborder:none\;\ndisplay:inline-block\;\nvertical-align:middle\;\ntext-align:center\;\nwhite-space:nowrap}\n";
HTML +=".button {\n";
HTML +=" border: none\;\n color: white\;\n padding: 15px 32px\;\n";
HTML +=" text-align: center\;\n";
HTML +=" text-decoration: none\;\n";
HTML +=" display: inline-block\;\n";
HTML +=" font-size: 25px\;\n";
HTML +=" margin: 4px 2px\;\n";
HTML +=" cursor: pointer\;\n";
HTML +="} \n";
HTML +="</style>\n\n";
if(useAjax)
{
HTML +="<script src=\"https://ajax.googleapis.com/ajax/libs/jquery/3.5.1/jquery.min.js\"></script>\n\n";
HTML +="<script>\n";
HTML +="$(document).ready(function(){\n";
HTML +="function loadTemp(){\n";
HTML +=" $('#div1').load(";
if(type =='C'){
HTML +="\"\/c\"\n";
}else if(type =='F')
{
HTML +="\"\/f\"\n";
}else{
HTML +="\"\/k\"\n";
}
HTML +=",function () {\n";
HTML +=" $(this).unwrap()\;\n";
HTML +=" })\;\n";
HTML +="}\n";
HTML +="loadTemp()\;\n";
HTML +="setInterval(function(){\n";
HTML +=" loadTemp() \n";
HTML +="}, 5000)\;\n";
HTML +="})\; </script> \n";
}
HTML +="</head>\n\n<body>\n<h1>Robojax MAX6675 Thermocouple</h1>\n";
HTML +="<h1>";
HTML +=titleMain;
HTML +="</h1>\n";
HTML +="<div id=\"div1\" style=\"background-color: #aecbd6 !important\; display: inline-block\; margin: 10px\"><h2>";
if(useAjax)
{
HTML +="<div id=\"div1\"><h2>";
HTML +=titleTemp;
HTML +="</h2></div>\n";
}else{
if(type =='C'){
HTML +="<span style=\"font-size: 28px\">\n";
HTML +=titleTemp;
HTML +=tempC;
HTML +="°C</span><br/>\n";
}
if(type =='F')
{
HTML +="<span style=\"font-size: 28px\">\n";
HTML +=titleTemp;
HTML +=tempF;
HTML +="°F</span><br/>\n";
}
if(type =='K')
{
HTML +="<span style=\"font-size: 28px\">\n";
HTML +=titleTemp;
HTML +=tempK;
HTML +="°K</span><br/>\n";
}
}//if ajax
HTML +="<br/>";
if(!useAjax)
{
HTML +="<a href=\"/c\" class=\"button\" style=\"background-color: #4CAF50\">Get °C</a>\n";
HTML +="<a href=\"/f\" class=\"button\" style=\"background-color: #4389fa\">Get °F</a>\n";
HTML +="<a href=\"/k\" class=\"button\" style=\"background-color: #fa5e43\">Get °K</a>\n";
}
HTML +="</div>\n"; //background color div
HTML +="\t\n</body>\n</html>\n";
server.send(200, "text/html", HTML);
//Robojax.com MAX6675 with ESP8622 with Ajax
}//handleRoot()
void handleNotFound() {
//Robojax.com MAX6675 with ESP8622 with Ajax
String message = "File Not Found\n\n";
message += "URI: ";
message += server.uri();
message += "\nMethod: ";
message += (server.method() == HTTP_GET) ? "GET" : "POST";
message += "\nArguments: ";
message += server.args();
message += "\n";
for (uint8_t i = 0; i < server.args(); i++) {
message += " " + server.argName(i) + ": " + server.arg(i) + "\n";
}
server.send(404, "text/plain", message);
}//handleNotFound()
void setup() {
//Robojax.com MAX6675 Thermocouple
Serial.begin(115200);
Serial.println("MAX6675 with ESP8266");
WiFi.mode(WIFI_STA);
WiFi.begin(ssid, password);
Serial.println("");
// Wait for connection
while (WiFi.status() != WL_CONNECTED) {
delay(500);
Serial.print(".");
}
Serial.println("");
Serial.print("Connected to ");
Serial.println(ssid);
Serial.print("IP address: http://");
Serial.println(WiFi.localIP());
//multicast DNS //Robojax.com Tutorial
if (MDNS.begin("robojaxESP8266")) {
Serial.println("MDNS responder started");
Serial.println("access via http://robojaxESP8266");
}
server.on("/", handleRoot);
if(useAjax)
{
server.on("/c", displayTempCA);
server.on("/f", displayTempFA);
server.on("/k", displayTempKA);
}else{
server.on("/c", displayTempC);
server.on("/f", displayTempF);
server.on("/k", displayTempK);
}
server.on("/inline", []() {
server.send(200, "text/plain", "this works as well");
});
server.onNotFound(handleNotFound);
server.begin();
Serial.println("HTTP server started");
//Robojax.com MLX90614 with ESP8622
// wait for MAX chip to stabilize
delay(500);
//Robojax.com MAX6675 Thermocouple
}// end of setup
void loop() {
//Robojax.com MAX6675 Thermocouple
server.handleClient();
MDNS.update();
readTemperature();
if(tempC >=89.5)
{
///do something here
}
handleRoot();
delay(1000);
//Robojax.com MAX6675 Thermocouple
}//loop
/*
* readTemperature()
* @brief Reads the temperature based on the TEMPERATURE_UNIT
* @param Average temperature
* @return Returns one of the values above
* Written by Ahmad Shamshiri for robojax.com
* on May 20, 2020 at 15:23 in Ajax, Ontario, Canada
*/
void readTemperature()
{
//Robojax.com with MAX6675 Thermocouple
tempF = thermocouple.readFahrenheit();//convert to Fahrenheit
tempK= thermocouple.readCelsius() + 273.15;//convert to Kelvin
tempC = thermocouple.readCelsius();// return Celsius
//Robojax.com MAX6675 Thermocouple
}// readTemperature()
void displayTempC()
{
//Robojax.com MAX6675 with ESP8622
type ='C';
handleRoot();
}//displayTempC()
void displayTempF()
{
//Robojax.com MAX6675 with ESP8622
type ='F';
handleRoot();
}//displayTempF()
void displayTempK()
{
//Robojax.com MAX6675 with ESP8622
type ='K';
handleRoot();
}//displayTempK()
/////////////////// functions for Ajax
void displayTempCA()
{
//Robojax.com MAX6675 with ESP8622
String HTML ="<span style=\"font-size: 28px\">\n";
HTML +=titleTemp;
HTML +=tempC;
HTML +="°C</span><br/>\n";
server.send(200, "text/html", HTML);
}//displayTemp()
void displayTempFA()
{
//Robojax.com MAX6675 with ESP8622
String HTML ="<span style=\"font-size: 28px\">\n";
HTML +=titleTemp;
HTML +=tempF;
HTML +="°F</span><br/>\n";
server.send(200, "text/html", HTML);
}//displayTemp()
void displayTempKA()
{
//Robojax.com MAX6675 with ESP8622 with Ajax
String HTML ="<span style=\"font-size: 28px\">\n";
HTML +=titleTemp;
HTML +=tempK;
HTML +="°K</span><br/>\n";
server.send(200, "text/html", HTML);
}//displayTempKA()文件📁
