XY6020L Numerical Control DC 6-70V Step Down Stabilized Power Supply Constant Voltage Current Buck Converter Module 20A/1200W
The XY6020L is a sophisticated, high-performance step-down converter designed for precision and durability. Utilizing high-quality materials and synchronous rectification technology, this 1200W power supply delivers a typical efficiency of 95%. Whether you are a hobbyist or a professional, its large, full-view dedicated power LCD provides a crystal-clear display of vital statistics, while the integrated CNC control ensures stable constant voltage and constant current output. Its robust design is complemented by advanced serial communication capabilities, supporting the standard MODBUS protocol for seamless remote control and integration into complex power management systems.
- High-performance XY6020L CNC DC Buck Converter with adjustable DC voltage output, delivering a constant voltage of up to 60V and 20A, making it ideal for various applications requiring a reliable power supply
- This 1200W Voltage Step Down Module Buck Converter ensures precise voltage regulation with a measurement resolution of 0.01V and accuracy of 0.4%, providing stable power output for your projects
- Equipped with advanced protection features such as overvoltage, undervoltage, overcurrent, and overtemperature protection, the XY6020L Buck Converter offers enhanced safety and longevity for your devices and circuits
- The adjustable voltage and current settings, along with a wide input voltage range of 6.0~70V, make this DC Buck Converter a versatile choice for DIY electronics enthusiasts, hobbyists, and professionals alike
- With a compact design and efficient cooling system, including a built-in fan that activates based on load and temperature, the XY6020L Buck Converter ensures reliable performance and durability in various power conversion applications
Key Features
- Built with high-quality materials for long-term durability[cite: 2].
- Advanced CNC DC stabilized voltage power supply featuring constant voltage (CV) and constant current (CC) modes[cite: 3].
- Large, full-view LCD screen dedicated to power monitoring[cite: 4].
- Supports Serial Communication and standard MODBUS protocol for remote operation[cite: 5].
- Comprehensive display interface with simple operation and highly stable performance[cite: 6].
-
XY6020L_BW-Display-image-5
Technical Specifications
| Parameter | Value / Specification |
|---|---|
| Input Voltage | 6.0 ~ 70V [cite: 8] |
| Output Voltage | 0.0 ~ 60V [cite: 9] |
| Output Current | 0 ~ 20.00A [cite: 10] |
| Output Power | 0 ~ 1200W [cite: 12] |
| Max Output Voltage | (Input Voltage + 1.1) - 2 [cite: 13] |
| Output Ripple | 100mv VPP (Typical) [cite: 11] |
| Measurement Resolution | 0.01V (Voltage) / 0.01A (Current) [cite: 14, 16] |
| Voltage Accuracy | $\pm0.4\%+1$ word [cite: 18] |
| Current Accuracy | $\pm0.5\%+3$ words [cite: 19] |
| Fan Trigger | Current > 2A, Power > 50W, or Temp > 50°C [cite: 20] |
Safety & Protection Mechanisms
Input Overvoltage (71V) Output Overcurrent (0-16A) Over Power Protection (0-950W) Over Temperature (95°C Default) Input Undervoltage (4.8-71V) External Temp Protection Timeout Protection Overcapacity/Energy Protection
Images
XY6020L_BW-Display-image-5
XY6020L_BW-Display-image-4
XY6020L_BW-Display-image-3
XY6020L_BW-Display-image-2
XY6020L_BW-Display-image-1
No code attached.
Things you might need
-
Amazon
-
AliExpressBuy XY6020L (color screen)1200W Step Down converter from AliExpresss.click.aliexpress.com
-
AliExpressBuy XY6020L 1200W Step Down converter from AliExpresss.click.aliexpress.com
Resources & references
No resources yet.
Files📁
User’s Manual
-
XY6020L 1200W_step_down_converter_user_manual Black-white displaythis is the user manual for the black and white display
XY6020L 1200W_step_down_converter_user_manual-1.pdf2.05 MB
