شِفر (کود) آردوینو برای صفحه‌نمایش LCD نوکیا 5110

شِفر (کود) آردوینو برای صفحه‌نمایش LCD نوکیا 5110


در این آموزش چگونگی استفاده از صفحه‌نمایش LCD نوکیا 5110 با آردوینو برای نمایش گرافیک‌ها و متن‌های مختلف را بررسی خواهیم کرد. این پروژه نشان خواهد داد چگونه خطوط، دایره‌ها و مستطیل‌ها را رسم کرده و حتی متن را درون این اشکال نمایش دهیم. در پایان، درک بهتری از نحوهٔ تعامل با این LCD با استفاده از شِفر (کود) آردوینو خواهید داشت.

Nokia 5110_LCD

برای ارائه راهنمایی روشن‌تر، توصیه می‌کنم ویدیوی مرتبط را برای نمایش بصری سیم‌کشی و پیاده‌سازی شِفر (کود) تماشا کنید (در ویدئو در 00:00).

سخت‌افزار توضیح داده شده

نمایشگر LCD نوکیا 5110 یک نمایشگر گرافیکی جمع‌وجور است که بر پایهٔ پروتکل SPI کار می‌کند و ارتباط کارآمدی با آردوینو فراهم می‌آورد. این نمایشگر دارای وضوح 84x48 پیکسل است که برای نمایش گرافیک‌ها و متون پایه کافی است. نمایشگر تنها به چند پایه برای کار نیاز دارد، که آن را گزینه‌ای عالی برای پروژه‌هایی با امکانات ورودی/خروجی محدود می‌سازد.

علاوه بر ال‌سی‌دی، به یک برد آردوینو، معمولاً آردوینو Uno یا مشابه، یک بردبورد و چند سیم جامپر نیاز خواهید داشت. سیم‌کشی ساده است و ال‌سی‌دی با اتصال پایه VCC آن به خروجی 5V آردوینو تغذیه می‌شود.

جزئیات مشخصات فنی

تولیدکنندهفیلیپس
شماره قطعهPCD8544
ولتاژ منطق/ورودی-خروجی3.3 ولت
ولتاژ تغذیه3.3 - 5.0 ولت
حداکثر جریان200 میکروآمپر
وضوح صفحه نمایش84 x 48 پیکسل
رابطسریال (SPI)
بستهماجیول

  • برای جلوگیری از آسیب، از یک مقاومت محدودکننده جریان برای پایه LED استفاده کنید.
  • مطمئن شوید اتصالات به VCC و GND محکم باشند تا از بروز مشکلات نمایش جلوگیری شود.
  • اتصالات پایه‌های SPI را دوباره بررسی کنید: SCE، RST، D/C، DN و SCLK.
  • تنظیم کنتراست را در محدوده توصیه‌شده (40-60) نگه دارید.
  • پس از ترسیم گرافیک‌ها، نمایش را به‌روزرسانی کنید تا تغییرات را ببینید.

دستورالعمل‌های سیم‌کشی

Arduino wiring for Nokia 5110 LCD
Arduino wiring for Nokia 5110 LCD

برای سیم‌کشی نمایشگر LCD نوکیا 5110 به آردوینو خود، از اتصالات زیر پیروی کنید:

  • LCDها را وصل کنیدVCCپایه به آردوینو5Vپایه.
  • متصل کنیدGNDپایه روی LCD به یکی از پایه‌های آردوینوGNDپایه‌ها.
  • متصل کنیدSCEپایه روی LCD به پایه7روی آردوینو.
  • وصل کنیدRSTپایه به پایه6.
  • وصل کنیدD/Cپایه به پایه5.
  • متصل کنیدDN (MOSI)پایه به پایه11.
  • وصل کنیدSCLKپایه‌به‌پایه13.
  • در نهایت، ... را وصل کنیدLEDپایه به پایه9از طریق یک مقاومت 330 اهم.

این اتصالات به آردوینو اجازه می‌دهند تا به‌طور مؤثر با LCD ارتباط برقرار کند. اگر نیاز به تنظیم سیم‌کشی برای راه‌اندازی خاص خود دارید، اطمینان حاصل کنید که پایه‌های SPI ثابت باقی بمانند.

نمونه‌کدها و راهنمای گام‌به‌گام

قطعه شِفر (کود) زیر LCD را مقداردهی اولیه کرده و کنتراست را تنظیم می‌کند:


void setup() {
  Serial.begin(9600);
  lcdBegin(); // Initialize the LCD
  setContrast(40); // Set contrast level
  delay(2000);
  clearDisplay(BLACK); // Clear the display
  updateDisplay(); // Update the display
}

در این قطعه،lcdBegin()تابع پایه‌های لازم برای LCD را راه‌اندازی می‌کند، در حالی کهsetContrast(40)کنتراست نمایشگر را تنظیم می‌کند. پس از یک تأخیر کوتاه، نمایشگر پاک می‌شود تا برای محتوای جدید آماده شود.

Nokia 5110_LCD back view

سپس می‌توانیم یک خط روی نمایشگر رسم کنیم:


setLine(1, 4, 70, 4, BLACK); // Draw a horizontal line
updateDisplay(); // Make the line visible

این خط شِفر (کود) استفاده می‌کندsetLine()تابع، که مختصات شروع و پایان را به همراه یک پارامتر رنگ می‌پذیرد. پس از رسم، ضروری است آن را فراخوانی کنیدupdateDisplay()برای انعکاس تغییرات روی صفحه نمایش.

در نهایت می‌توانیم متن را درون یک مستطیل نمایش دهیم:


setRect(10, 10, 70, 40, 1, BLACK); // Draw a filled rectangle
setStr("Robojax ", 15, 20, WHITE); // Display text inside
updateDisplay(); // Update to show the changes

اینجا،setRect()یک مستطیل ایجاد می‌کند، در حالی کهsetStr()متن را داخل آن قرار می‌دهد. پارامترهای رنگ تعیین می‌کنند که مستطیل و متن چگونه روی صفحه نمایش ظاهر شوند.

نمایش / چه انتظاری داشته باشید

پس از اجرای شِفر (کود) باید مجموعه‌ای از گرافیک‌ها روی نمایشگر Nokia 5110 LCD ببینید، از جمله خطوط، دایره‌ها، مستطیل‌ها و متن. از درست بودن سیم‌کشی مطمئن شوید تا از مشکلاتی مانند قطبیت معکوس یا ورودی‌های شناور که ممکن است مانع عملکرد نمایشگر شوند جلوگیری کنید (در ویدئو در :30).

برچسب‌های زمانی ویدیو

  • 00:00- مقدمه‌ای بر پروژه
  • 01:30دستورالعمل سیم‌کشی
  • 03:00- راه‌اندازی و توضیح شِفر (کود)
  • 05:00- نمایش گرافیک‌ها و متن
  • 07:30- نتیجه‌گیری و اصلاحات بیشتر

تصاویر

Nokia 5110_LCD back view
Nokia 5110_LCD back view
Arduino wiring for Nokia 5110 LCD
Arduino wiring for Nokia 5110 LCD
Nokia 5110_LCD
Nokia 5110_LCD
82-Arduino code: Dual-axis joystick with Nokia 5110 screen to display dots.
زبان: C++
/*
 * This is Arduino code to use a dual-axis XY joystick with a Nokia 5110 LCD.
 * It also reads a switch.
 * Other Arduino libraries and videos: https://robojax.com

 * Watch the video for this code to learn it fully.
  * Watch the video here: https://youtu.be/Pk5Wig5EO0s

 *
 * Get this code and other Arduino codes from Robojax.com.
 Learn Arduino step by step in a structured course with all material, wiring diagrams, and libraries
 all in one place. Purchase my course on Udemy.com: http://robojax.com/L/?id=62

If you found this tutorial helpful, please support me so I can continue creating
content like this. You can support me on Patreon: http://robojax.com/L/?id=63

or make a donation using PayPal: http://robojax.com/L/?id=64

 *  * This code is "AS IS" without warranty or liability. Free to be used as long as you keep this note intact. *
 * This code has been downloaded from Robojax.com
    This program is free software: you can redistribute it and/or modify
    it under the terms of the GNU General Public License as published by
    the Free Software Foundation, either version 3 of the License, or
    (at your option) any later version.

    This program is distributed in the hope that it will be useful,
    but WITHOUT ANY WARRANTY; without even the implied warranty of
    MERCHANTABILITY or FITNESS FOR A PARTICULAR PURPOSE.  See the
    GNU General Public License for more details.

    You should have received a copy of the GNU General Public License
    along with this program.  If not, see <https://www.gnu.org/licenses/>.


Nokia 5110 LCD Example Code
   Graphics driver and PCD8544 interface code for SparkFun's
   84x48 Graphic LCD.
   https://www.sparkfun.com/products/10168
   Original source code:
https://github.com/sparkfun/GraphicLCD_Nokia_5110

  This stuff could all be put into a library, but we wanted to
  leave it all in one sketch to keep it as transparent as possible.

  Hardware: (Note: most of these pins can be swapped)
    Graphic LCD Pin ---------- Arduino Pin
       1-VCC       ----------------  5V
       2-GND       ----------------  GND
       3-SCE       ----------------  7
       4-RST       ----------------  6
       5-D/C       ----------------  5
       6-DN(MOSI)  ----------------  11
       7-SCLK      ----------------  13
       8-LED       - 330 Ohm res --  9
   The SCLK, DN(MOSI), must remain where they are, but the other
   pins can be swapped. The LED pin should remain a PWM-capable
   pin. Don't forget to stick a current-limiting resistor in line
   between the LCD's LED pin and Arduino pin 9!
   Modified by Ahmad S. for Robojax.com
   on Mar 11, 2018 at 20:49 in Ajax, Ontario, Canada
*/
#include <SPI.h>
#include "robojax-nokia5110.h"

void setup()
{
  Serial.begin(9600);

  lcdBegin(); // This will setup our pins, and initialize the LCD
  //updateDisplay(); // with displayMap untouched, SFE logo
  setContrast(40); // Good values range from 40-60
  delay(2000);

  clearDisplay(BLACK);
  updateDisplay();
}


void loop()
{

    // setPixel takes 2 to 3 parameters. The first two parameters
    // are x and y variables. The third optional parameter is
    // a "color" boolean. 1 for black, 0 for white.
    // setPixel() with two variables will set the pixel with
    // the color set to black.
    // clearPixel() will call setPixel with the color set to
    // white.
   // setPixel(random(0, LCD_WIDTH), random(0, LCD_HEIGHT));
    // After drawing something, we must call updateDisplay()
    // to actually make the display draw something new.

    //invertDisplay(); // This will swap all bits in our display

    // setLine(x0, y0, x1, y1, bw) takes five parameters. The
    // first four are coordinates for the start and end of the
    // line. The last parameter is the color (1=black, 0=white).
    setLine(1, 4, 70, 4, BLACK);
    updateDisplay();
delay(2000);
    //analogWrite(blPin, i); // blPin is connected to BL LED

  /* setRect Example */
  clearDisplay(WHITE); // Start fresh

  // setCircle takes 5 parameters -- x0, y0, radius, bw, and
  // lineThickness. x0 and y0 are the center coordinates of the circle.
  // radius is the...radius. bw is the color (0=white, 1=black)
  // lineThickness is the line width of the circle, 1 = smallest
  // thickness moves in towards the center.
   setCircle(20, 30, 20, BLACK, 2);
  updateDisplay();
  delay(2000);
clearDisplay(WHITE);

  setStr("Welcome to ", 0, 0, BLACK);
      updateDisplay();
    delay(100);
  setLine(0, 9, 70, 9, BLACK);
    updateDisplay();
    delay(100);
   setStr("Robojax ", 20, 20, BLACK);
  updateDisplay();
  delay(2000);
  clearDisplay(WHITE);


  // setRect takes six parameters (x0, y0, x1, y0, fill, bw)
  // x0, y0, x1, and y0 are the two diagonal corner coordinates
  // fill is a boolean, which determines if the rectangle is
  // filled in. bw determines the color 0=white, 1=black.
    setRect(10, 10, 70, 40, 1, BLACK);
    setStr("Robojax ", 15, 20, WHITE);
    updateDisplay();
  delay(2000);

  /* setCircle Example */
  clearDisplay(WHITE);

}
