 * //original source is http://www.geeetech.com/wiki/index.php/Stepper_Motor_5V_4-Phase_5-Wire_%26_ULN2003_Driver_Board_for_Arduino
 * //APDS-9960 RGB and Gesture Sensor
 * //Shawn Hymel @ SparkFun Electronics
 * //May 30, 2014
 * //https://github.com/sparkfun/APDS-9960_RGB_and_Gesture_Sensor
 * // This code is used with a video tutorial for RoboJax.com
 * // Published on May 11, 2017 from Aajx, ON, Canada.
 * /*
 * Must watch this two videos
 * 1-Stepper motor
 * https://www.youtube.com/watch?v=Sl2mzXfTwCs
 *
 * 2-Gesture sensor
 * https://www.youtube.com/watch?v=qzSgZV_fbxI
 *
 * Download the code from:
 * http://roboJax.com/learn/arduino
 */
#include <Wire.h>
#include <SparkFun_APDS9960.h>


int Pin1 = 10; // pin di controllo motore 1
int Pin2 = 11; // pin di controllo del motore 2
int Pin3 = 12; // pin di controllo motore 3
int Pin4 = 13; // pin di controllo motore 4
int _step = 0;
boolean dir = false; // falso=orario, vero=antiorario
int count=0;
int action; // stop=1, CCW=2, CW=3

 // Perni
#define APDS9960_INT    2 // Deve esserci un pin di interruzione.
 // Variabili Globali
SparkFun_APDS9960 apds = SparkFun_APDS9960();
int isr_flag = 0;

void setup()
{
 // impostazione del motore passo-passo
 pinMode(Pin1, OUTPUT);
 pinMode(Pin1, OUTPUT);
 pinMode(Pin2, OUTPUT);
 pinMode(Pin4, OUTPUT);
 // / ************* impostazione del motore passo-passo fine
 // Imposta il pin di interruzione come ingresso
  pinMode(APDS9960_INT, INPUT);


 // Inizializza la porta seriale
  Serial.begin(9600);
  Serial.println();
  Serial.println(F("--------------------------------"));
  Serial.println(F("SparkFun APDS-9960 - GestureTest"));
  Serial.println(F("--------------------------------"));

 // Inizializza la routine di servizio per le interruzioni
  attachInterrupt(0, interruptRoutine, FALLING);

 // Inizializza APDS-9960 (configura I2C e valori iniziali)
  if ( apds.init() ) {
    Serial.println(F("APDS-9960 initialization complete"));
  } else {
    Serial.println(F("Something went wrong during APDS-9960 init!"));
  }

 // Inizia a eseguire il motore del sensore di gesti APDS-9960
  if ( apds.enableGestureSensor(true) ) {
    Serial.println(F("Gesture sensor is now running"));
  } else {
    Serial.println(F("Something went wrong during gesture sensor init!"));
  }
}
 void loop()
{

  if( isr_flag == 1 ) {
 // detachInterrupt(0);
   action = handleGesture();
    isr_flag = 0;
 // attachInterrupt(0, interruptRoutine, DISCESO);
  }

  if(action ==1){
    _step =9; // ferma il motore
  }else if(action ==2){
 // _step =0;
    dir = true; // Direzione di rotazione antioraria
  }else if(action ==3){
 // _step =0;//Direzione di rotazione oraria
    dir = false;
  }

 switch(_step){
   case 0:
     digitalWrite(Pin1, LOW);
     digitalWrite(Pin2, LOW);
     digitalWrite(Pin3, LOW);
     digitalWrite(Pin4, HIGH);
   break;
   case 1:
     digitalWrite(Pin1, LOW);
     digitalWrite(Pin2, LOW);
     digitalWrite(Pin3, HIGH);
     digitalWrite(Pin4, HIGH);
   break;
   case 2:
     digitalWrite(Pin1, LOW);
     digitalWrite(Pin2, LOW);
     digitalWrite(Pin3, HIGH);
     digitalWrite(Pin4, LOW);
   break;
   case 3:
     digitalWrite(Pin1, LOW);
     digitalWrite(Pin2, HIGH);
     digitalWrite(Pin3, HIGH);
     digitalWrite(Pin4, LOW);
   break;
   case 4:
     digitalWrite(Pin1, LOW);
     digitalWrite(Pin2, HIGH);
     digitalWrite(Pin3, LOW);
     digitalWrite(Pin4, LOW);
   break;
   case 5:
     digitalWrite(Pin1, HIGH);
     digitalWrite(Pin2, HIGH);
     digitalWrite(Pin3, LOW);
     digitalWrite(Pin4, LOW);
   break;
     case 6:
     digitalWrite(Pin1, HIGH);
     digitalWrite(Pin2, LOW);
     digitalWrite(Pin3, LOW);
     digitalWrite(Pin4, LOW);
   break;
   case 7:
     digitalWrite(Pin1, HIGH);
     digitalWrite(Pin2, LOW);
     digitalWrite(Pin3, LOW);
     digitalWrite(Pin4, HIGH);
   break;
   default:
     digitalWrite(Pin1, LOW);
     digitalWrite(Pin2, LOW);
     digitalWrite(Pin3, LOW);
     digitalWrite(Pin4, LOW);
   break;
 }
 if(dir){
   _step++;
 }else{
   _step--;
 }
 if(_step>7){
   _step=0;
 }
 if(_step<0){
   _step=7;
 }
 delay(1);

} // ciclo

void interruptRoutine() {
  isr_flag = 1;
}


int handleGesture() {
    if ( apds.isGestureAvailable() ) {
    switch ( apds.readGesture() ) {

      case DIR_DOWN:
        Serial.println("DOWN--Stop");
        return 1;
        break;
      case DIR_LEFT:
        Serial.println("LEFT-- Counterclockwise");
        return 2;
        break;
      case DIR_RIGHT:
        Serial.println("RIGHT--Clockwise");
        return 3;
        break;

      default:
      return 1; // spegnere
        Serial.println("NONE Stopped");
    }
  }
}
