 * Lesson 58: What is a multidimensional array? RGB LED example


  * Works for both Common Anode and Common Cathode RGB LEDs
 * This Arduino sketch is to control color on an RGB LED

 Please watch full detailed video: https://youtu.be/YuGJpFeoq5I
 Location of this code: https://robojax.com/course1/?vid=lecture59

 * Written by Ahmad Shamshiri for Robojax.com
 * on October 6th, 2018 at 14:00 in Ajax, Ontario, Canada



If you found this tutorial helpful, please support me so I can continue creating
content like this.

or make a donation using PayPal http://robojax.com/L/?id=64

 *  * This code is "AS IS" without warranty or liability. Free to be used as long as you keep this note intact.*
 * This code has been downloaded from Robojax.com
    This program is free software: you can redistribute it and/or modify
    it under the terms of the GNU General Public License as published by
    the Free Software Foundation, either version 3 of the License, or
    (at your option) any later version.

    This program is distributed in the hope that it will be useful,
    but WITHOUT ANY WARRANTY; without even the implied warranty of
    MERCHANTABILITY or FITNESS FOR A PARTICULAR PURPOSE.  See the
    GNU General Public License for more details.

    You should have received a copy of the GNU General Public License
    along with this program.  If not, see <https://www.gnu.org/licenses/>.
 */
int RED = 11;// the PWM pin the RED LED is attached to
int GREEN = 10;// the PWM pin the GREEN LED is attached to
int BLUE = 9;// the PWM pin the BLUE LED is attached to
int colorTime = 2000; // time to wait between color change
int type =1; // 0 for common cathode LED
             // 1 for common anode LED


int color[8][3] =
              {
               {255,255,255},// white
               {255,0,    0},// red
               {0,  255,  0},// green
               {0, 0,   255},// blue
               {255,255,  0},// yellow
               {0,  255,255},// aqua
               {255,0,  255},// pink
               {255,125,  0},//Orange
              };
String colorName[8]=
              {
               "White",
               "Red",
               "Green",
               "Blue",
               "Yellow",
               "Aqua",
               "Pink",
               "Orange"
              };
void setup() {
   // Robojax.com RGB LED code 20181006
  Serial.begin(9600);
  // declare pin 11,12, 13 for RED , GREEN and BLUE to be an output:
  pinMode(RED, OUTPUT);
  pinMode(GREEN, OUTPUT);
  pinMode(BLUE, OUTPUT);

}

// the loop routine runs over and over again forever:
void loop() {

  // Robojax.com RGB LED code 20181006


  delay(3000);
    for(int j=0; j<8; j++)
      {
        RGB_LED(color[j][0], color[j][1], color[j][2]);
        Serial.println(colorName[j]);

      delay(colorTime);// delay for each color
      }

}

/*
  sends correct value to R, G and B and LED pin
  this function is for common cathode LEDs and converts regular PWM
  @param r is received red value
  @param g is received green value
  @param b is received blue value

 */
void RGB_LED(int r, int g, int b)
{
  if(type == 1)
  {
    r = 255-r;
    g = 255-g;
    b = 255-b;
  }
        analogWrite(RED, r);// set value for RED LED
        analogWrite(GREEN, g);// set value for GREEN LED
        analogWrite(BLUE, b);// set value for BLUE LED

}
