 * Lesson 63: Introduction to using relays with Arduino
 * This Arduino sketch controls a 5V relay module by turning it ON
 * or OFF at the set intervals.
 Watch full detailed video: https://youtu.be/N-xbxtGGoHw
 *

 * Written by Ahmad Shamshiri
 * on December 26, 2018 in Ajax, Ontario, Canada
 *
 This video is part of the Arduino Step by Step Course, which starts here: https://youtu.be/-6qSrDUA5a8



If you found this tutorial helpful, please support me so I can continue creating
content like this. You can support me on Patreon: http://robojax.com/L/?id=63

or make a donation using PayPal: http://robojax.com/L/?id=64

 *  * This code is "AS IS" without warranty or liability. Free to be used as long as you keep this note intact.*
 * This code has been downloaded from Robojax.com
    This program is free software: you can redistribute it and/or modify
    it under the terms of the GNU General Public License as published by
    the Free Software Foundation, either version 3 of the License, or
    (at your option) any later version.

    This program is distributed in the hope that it will be useful,
    but WITHOUT ANY WARRANTY; without even the implied warranty of
    MERCHANTABILITY or FITNESS FOR A PARTICULAR PURPOSE.  See the
    GNU General Public License for more details.

    You should have received a copy of the GNU General Public License
    along with this program.  If not, see <https://www.gnu.org/licenses/>.
 */

int relayPin = 2;// define output pin for relay

void setup() {
  pinMode(relayPin, OUTPUT);// define pin 2 as output

}

void loop() {

  digitalWrite(relayPin, LOW); // turn the relay ON
  delay(200); // wait for 3 seconds
  digitalWrite(relayPin, HIGH);// // turn the relay OFF
  delay(200);// wait for 1 second

  digitalWrite(relayPin, LOW); // turn the relay ON
  delay(200); // wait for 3 seconds
  digitalWrite(relayPin, HIGH);// // turn the relay OFF
  delay(200);// wait for 1 second

  digitalWrite(relayPin, LOW); // turn the relay ON
  delay(2000); // wait for 3 seconds
  digitalWrite(relayPin, HIGH);// // turn the relay OFF
  delay(1000);// wait for 1 second
}
