 * Original code is taken from the Arduino IDE
 * from File->Examples->Servo->Knob
 *
 * This is Arduino code to use a display to show the angle of a servo motor on an LCD1602 or LCD2004 with an I2C module. The angle is set and changed by a
 * potentiometer (variable resistor)
 *
 * This is code 2 of this tutorial where a breadboard is not needed.
 * 5V is provided from digital pins of the Arduino.
 *
 * See code SP-LCD-1:  http://robojax.com/L/?id=289
 *
 * Please watch video instruction: https://youtu.be/xrIiKqvm8hQ
 * Updated from original code by
 * Ahmad Shamshiri on Nov 22, 2020 at 15:53 in Ajax
 * Ontario, Canada
 * https://www.youtube.com/robojaxTV
 * www.robojax.com


 * Get this code and other Arduino codes from Robojax.com.
Learn Arduino step by step in a structured course with all material, wiring diagrams, and libraries
all in one place.

If you found this tutorial helpful, please support me so I can continue creating
content like this.

or make a donation using PayPal http://robojax.com/L/?id=64

 *  * This code is "AS IS" without warranty or liability. Free to be used as long as you keep this note intact.*
 * This code has been downloaded from Robojax.com
    This program is free software: you can redistribute it and/or modify
    it under the terms of the GNU General Public License as published by
    the Free Software Foundation, either version 3 of the License, or
    (at your option) any later version.

    This program is distributed in the hope that it will be useful,
    but WITHOUT ANY WARRANTY; without even the implied warranty of
    MERCHANTABILITY or FITNESS FOR A PARTICULAR PURPOSE.  See the
    GNU General Public License for more details.

    You should have received a copy of the GNU General Public License
    along with this program.  If not, see <https://www.gnu.org/licenses/>.
 */
#include <Wire.h>
#include <LiquidCrystal_I2C.h>
// Set the LCD address to 0x27 for a 16 chars and 2 line display

//LCD settings
const uint8_t I2C_ADDRESS =0x3f;//watch video. use I2C Scanenr to get the address
const uint8_t LCD_CHAR= 16;
const uint8_t LCD_LINE = 2;
char *TITLE_ANGLE1 ="Angle: ";

LiquidCrystal_I2C lcd(I2C_ADDRESS, LCD_CHAR, LCD_LINE);

#include <Servo.h>

// start of servo1 settings *******
Servo myservo1;  // create servo 1 object to control a servo
int pot1pin = A0;  // analog pin used to connect the potentiometer
unsigned int servo1Pin=3;//any pin with ~ which means pin is PWM enabled
unsigned int servo1AngleMin=0;//servo1 minimum angle
unsigned int servo1AngleMax=180;//servo1 maximum angle details
//// do not change the lines below
unsigned int servo1Val=0;// variable to read the value from the analog pin
unsigned int angle1=0;
// END of servo1 settings *******



void setup()
{
  Serial.begin(9600);

  Serial.println("Servo with Potentiometer");
  Serial.println("Robojax.com");
  myservo1.attach(servo1Pin);  // attaches the servo 1  to the servo object

  lcd.begin();
  lcd.backlight();
  lcd.print("Robojax Servo");
  lcd.setCursor(0,1);
  lcd.print("Angle: ");
  delay(2000);
}

void loop()
{
 servo1Val = analogRead(pot1pin);            // reads the value of the potentiometer (value between 0 and 1023)
 sendServo(servo1Val);//send sevo zero
delay(20);

}// loop end


/*
 * sendServo(int value)
 * @brief sends the servo the "value" angle position
 * @param "value" integer between 0 to 180
 * @return none
 * Written by Ahmad Shamshiri for robojax.com
 * on Nov 22, 2020  in Ajax, Ontario, Canada
 */
void sendServo(int value)
{
  // Please watch video instruction: https://youtu.be/xrIiKqvm8hQ
  unsigned int newAngle1;
  newAngle1 = map(value, 0, 1023, servo1AngleMin, servo1AngleMax);     // scale it to use it with the servo (value between servoAngleMin and servoAngleMax)
  if(angle1 !=newAngle1)
  {
  myservo1.write(newAngle1);
  lcdDisplay(newAngle1);
  angle1 =newAngle1;
  delay(100);
  }

}//sendServo()

/*
 * lcdDisplay(int angle)
 * @brief displays the "angle" angle position
 * @param "angle" integer between 0 to 180
 * @return none
 * Written by Ahmad Shamshiri for robojax.com
 * on Nov 22, 2020  in Ajax, Ontario, Canada
 */
void lcdDisplay(int angle)
{
 //Please watch video instruction: https://youtu.be/xrIiKqvm8hQ
   // Robojax.com LCD1602 for Servo motor
   clearCharacters();
      Serial.print("angle");
      Serial.println(angle);
   lcd.setCursor((unsigned)strlen(TITLE_ANGLE1), 1);
   lcd.print(angle);//print value of angle
   lcd.print((char)223);
} //


/*
   clearCharacters()
 * @brief clears a line of the display (erases all characters)
 * @param none
 * @return does not return anything
 * Written by Ahmad Shamshiri
 * www.Robojax.com code May 28, 2020 at 16:21 in Ajax, Ontario, Canada
 */
void clearCharacters()
{
    for (int i=(unsigned)strlen(TITLE_ANGLE1)-1; i<=LCD_CHAR-1; i++)
    {
    lcd.setCursor (i,1); //
    lcd.write(254);
    }

}//clearCharacters
