Review of DC 1500W 30A Boost Converter, 10V-60V to 12V-90V Module
In this tutorial, we will explore how to utilize the DC 1500W 30A Boost Converter, which can convert input voltages ranging from 10V to 60V to a stable output of 12V to 90V. This device is particularly useful in applications where a higher voltage is required from a lower voltage source, such as powering devices that demand higher voltage levels from batteries or other low-voltage sources. By the end of this guide, you will understand how to properly wire the converter and utilize it for various applications.

It's essential to understand the key components of the boost converter to use it effectively. The converter operates by increasing the input voltage through a process called inductive boosting, using an inductor and a switch (typically a transistor) to store and release energy. This allows for a higher output voltage while maintaining the necessary current levels for your devices.
Hardware Explained
The primary components of the DC 1500W Boost Converter include the following:

- Inductor: This component stores energy when the switch is closed and releases it when the switch is open, resulting in increased voltage.
- Switch (Transistor): This component controls the flow of current in the circuit, switching on and off rapidly to regulate the output voltage.
- Diode: This prevents backflow of current, ensuring that the energy stored in the inductor only flows towards the output.
- Capacitor: This component smooths out the output voltage, providing a stable voltage to your load.
- Voltage Regulator: This ensures the output voltage remains within the desired range, providing protection against overvoltage conditions.
Datasheet Details
| Manufacturer | Generic |
|---|---|
| Part number | DC-DC Boost Converter 1500W |
| Input voltage range | 10–60 V |
| Output voltage range | 12–90 V |
| Output current | 30 A max |
| Efficiency | ≥ 95% |
| Operating temperature | -40 to +85 °C |
| Protection features | Overvoltage, overcurrent, thermal shutdown |
| Package | Standard PCB module |
- Ensure proper heat dissipation; consider adding a heatsink.
- Verify input and output connections before powering on.
- Use capacitors rated above the maximum output voltage for stability.
- Check the polarity of connections to avoid damage.
- Monitor the output voltage under load to ensure stability.
Wiring Instructions
To wire the DC Boost Converter, start by connecting the power input. Connect the positive input terminal (often labeled VIN+) to your power source, ensuring it is within the 10V-60V range. The negative terminal (labeled VIN-) should be connected to the ground of your power source.
Next, connect the output terminals. The positive output terminal (usually VOUT+) should be connected to the load that requires the boosted voltage, while the negative output terminal (labeled VOUT-) should also be connected to the ground. Ensure that all connections are secure to prevent any interruptions in power delivery.

Video Timestamps
- 00:00 Start
- 02:03 Introduction to the 1500W module
- 06:04 Hardware Explained
- 10:37 Components Explained
- 14:40 Setting current limit
- 15:21 Input/Output Minimum/Maximum
- 16:36 Test preparation
- 17:16 Input 60V Tests
- 31:49 Input 50V Tests
- 35:50 Input 36V Tests
- 37:44 Input 24V Tests
- 39:10 Input 18V Tests
- 39:53 Input 12V Test
- 40:37 Charging Battery
- 43:19 Under-Voltage Protection
- 47:23 Ripple Voltage measurement
- 48:19 Concluding Remarks
