How to Use the XH-W3001 AC Digital Thermostat
This is a digital thermostat that can be used as a heater controller or cooler controller. The load it can control can be either AC or DC. It is powered via an AC power line. The voltage depends on the region, either 120V or 220V AC.
XH-W3001 AC digital Thermostat: Main view
Click on image to enlarge
XH-W3001 AC digital Thermostat: inside view
Click on image to enlarge
XH-W3001 AC digital Thermostat: output light
Click on image to enlarge
XH-W3001 AC digital Thermostat: back view voltage rating
Click on image to enlarge
XH-W3001 AC digital Thermostat: length
Click on image to enlarge
XH-W3001 AC digital Thermostat: width
Click on image to enlarge
XH-W3001 AC digital Thermostat: Heater control example
Click on image to enlarge
XH-W3001 AC digital Thermostat: Cooler control example
Click on image to enlarge
XH-W3001 AC digital Thermostat: AC load control shown
Click on image to enlarge
XH-W3001 AC digital Thermostat: Cooler control settings
Click on image to enlarge
XH-W3001 AC digital Thermostat: Heater control settings
Click on image to enlarge
LLL and HHH displays
When LLL is displayed, the temperature probe is not inserted, disconnected, damaged, and needs replacing. When HHH is displayed, the temperature probe is short-circuited and the temperature detection range is exceeded.
