Reading Temperatures Wirelessly over Wi-Fi with DHT11, DHT22, and ESP8266 NodeMCU

Video thumbnail for How to use DHT11 DHT22 with NodeMCU ESP8266 to read temperature over WiFi - RJT222
تماشا در یوتیوب

Reading Temperatures Wirelessly over Wi-Fi with DHT11, DHT22, and ESP8266 NodeMCU

This video shows you how to use a DHT11 with an ESP8266 to read temperature over Wi-Fi on a computer or mobile device in a home Wi-Fi network.

URL to enter into the Preferences of the Arduino IDE: https://arduino.esp8266.com/stable/package_esp8266com_index.json

لطفاً اگر شِفر (کود) قابل مشاهده نیست، این صفحه را به انگلیسی مشاهده کنید. از ایجاد زحمت پوزش می‌طلبیم.
248-Download DHT code for ESP8266 and the Arduino IDE
زبان: C++
/*
 * Display temperature using DHT11, DHT22 with NodeMCU ESP8266 with Arduino IDE
 *
 * Written by Ahmad Shamshiri on Sep 27, 2019
 * in Ajax, Ontario, Canada
 * Watch video instruction for this video: https://youtu.be/1A4-6hDARQc
 *
 * I have combined DHT library of Adafruit with ESP8266 WebServer; both links are provided below:
 * Adafruit DHT library on GitHub: https://github.com/adafruit/DHT-sensor-library
 * and
 * ESP8266 on GitHub : https://github.com/esp8266/Arduino
 *
 *
Get this code and other Arduino codes from Robojax.com
You can get the wiring diagram from my Arduino Course at Udemy.com
Learn Arduino step by step with all libraries, codes, and wiring diagrams all in one place
visit my course now http://robojax.com/L/?id=62

If you found this tutorial helpful, please support me so I can continue creating
content like this.
or make a donation using PayPal http://robojax.com/L/?id=64

 * Code is available at http://robojax.com/learn/arduino
 * This code is "AS IS" without warranty or liability. Free to be used as long as you keep this note intact.
 * This code has been downloaded from Robojax.com
    This program is free software: you can redistribute it and/or modify
    it under the terms of the GNU General Public License as published by
    the Free Software Foundation, either version 3 of the License, or
    (at your option) any later version.

    This program is distributed in the hope that it will be useful,
    but WITHOUT ANY WARRANTY; without even the implied warranty of
    MERCHANTABILITY or FITNESS FOR A PARTICULAR PURPOSE.  See the
    GNU General Public License for more details.

    You should have received a copy of the GNU General Public License
    along with this program.  If not, see <https://www.gnu.org/licenses/>.

*/

const int refresh=3;//3 seconds
// DHT settings starts
#include "DHT.h"
#define DHTPIN 2     // what digital pin we're connected to
// Uncomment whatever type you're using!
//#define DHTTYPE DHT11   // DHT 11
#define DHTTYPE DHT22   // DHT 22  (AM2302), AM2321
//#define DHTTYPE DHT21   // DHT 21 (AM2301)
DHT dht(DHTPIN, DHTTYPE);
float tValue;//
// ****** DHT settings end (Robojax.com )


#include <ESP8266WiFi.h>
#include <WiFiClient.h>
#include <ESP8266WebServer.h>
#include <ESP8266mDNS.h>

#ifndef STASSID
#define STASSID "Wifi SSID" // Your WiFi SSID
#define STAPSK  "Secret Wifi password" //Your WiFi password
#endif

const char* ssid = STASSID;
const char* password = STAPSK;

ESP8266WebServer server(80);


void sendTemp() {

  String page = "<!DOCTYPE html>\n\n";
  page +="    <meta http-equiv='refresh' content='";
  page += String(refresh);// how often temperature is read
  page +="'/>\n";
  page +="<html>\n";
  page +="<body>\n";
  page +="<h1>Robojax.com DHT Code</h1>\n";
  page +="<p style=\"font-size:50px;\">Temperature<br/>\n";
  page +="<p style=\"color:red; font-size:50px;\">";
  page += String(tValue, 2);
  page +="</p>\n";
  page +="</body>\n";
  page +="</html>\n";
 server.send(200,  "text/html",page);

}

void handleNotFound() {

  String message = "File Not Found\n\n";
  message += "URI: ";
  message += server.uri();
  message += "\nMethod: ";
  message += (server.method() == HTTP_GET) ? "GET" : "POST";
  message += "\nArguments: ";
  message += server.args();
  message += "\n";
  for (uint8_t i = 0; i < server.args(); i++) {
    message += " " + server.argName(i) + ": " + server.arg(i) + "\n";
  }
  server.send(404, "text/plain", message);

}

void setup(void) {
  // Robojax.com code for ESP8266 and DHT11 DHT22
   dht.begin();
  Serial.begin(115200);
  WiFi.mode(WIFI_STA);
  WiFi.begin(ssid, password);
  Serial.println("");

  // Wait for connection
  while (WiFi.status() != WL_CONNECTED) {
    delay(500);
    Serial.print(".");
  }
  if (WiFi.status() == WL_CONNECTED)
  {
    uint8_t macAddr[6];
    WiFi.macAddress(macAddr);
    Serial.printf("Connected, mac address: %02x:%02x:%02x:%02x:%02x:%02x\n", macAddr[0], macAddr[1], macAddr[2], macAddr[3], macAddr[4], macAddr[5]);
  }
  Serial.println("");
  Serial.print("Connected to ");
  Serial.println(ssid);
  Serial.print("IP address: ");
  Serial.println(WiFi.localIP());

  if (MDNS.begin("robojaxDHT")) {
    Serial.println("MDNS responder started");
  }

  server.on("/", sendTemp);

  server.on("/inline", []() {
    server.send(200, "text/plain", "this works as well");
  });

  server.onNotFound(handleNotFound);

  server.begin();
  Serial.println("HTTP server started");
}

void loop(void) {
  // Robojax.com code for ESP8266 and DHT11 DHT22
  server.handleClient();
  MDNS.update();
  float c = dht.readTemperature();// Read temperature as Celsius (the default)
  float h = dht.readHumidity();// Reading humidity
  float f = dht.readTemperature(true);// Read temperature as Fahrenheit (isFahrenheit = true)
    Serial.println(c);
 tValue =c;
  delay(300);// change this to larger value (1000 or more) if you don't need very often reading
  // Robojax.com code for ESP8266 and DHT11 DHT22
}
