 *  74HC595 Seven Segment 2 Digits LED Display with decimal points for Arduino
 *  updated by Ahmad Shamshiri for Robojax
 *  On Monday, September 17, 2019 at 00:03 in Ajax, Ontario, Canada
 *
 *  Watch video instruction for this video: https://youtu.be/k-f6lwwUTAs
 *  At the moment, it doesn't display decimal points. It needs a little work to make it work.
 *
 * You can get the wiring diagram from my Arduino Course at Udemy.com.
 * Learn Arduino step by step with all libraries, codes, and wiring diagrams all in one place.
 * Visit my course now: http://robojax.com/L/?id=62
 *
 * If you found this tutorial helpful, please support me so I can continue creating
 * content like this. You can support me on Patreon: http://robojax.com/L/?id=63
 * or make a donation using PayPal: http://robojax.com/L/?id=64
 *
 * Code is available at: http://robojax.com/learn/arduino
 *
 * This code is "AS IS" without warranty or liability. Free to be used as long as you keep this note intact.
 * This code has been downloaded from Robojax.com
    This program is free software: you can redistribute it and/or modify
    it under the terms of the GNU General Public License as published by
    the Free Software Foundation, either version 3 of the License, or
    (at your option) any later version.

    This program is distributed in the hope that it will be useful,
    but WITHOUT ANY WARRANTY; without even the implied warranty of
    MERCHANTABILITY or FITNESS FOR A PARTICULAR PURPOSE.  See the
    GNU General Public License for more details.

    You should have received a copy of the GNU General Public License
    along with this program.  If not, see <https://www.gnu.org/licenses/>.


 *  Original source and text.
 *  2-Digit 7-segment display PCB board with (2) 74HC595 shift register ICs
 *  Arduino Tutorial - www.Ardumotive.com
 *  Dev: Michalis Vasilakis // Date: 31/1/2018 // Ver:1.0
 */
#include <ShiftRegister74HC595.h>
#define SDI 7
#define SCLK 6
#define LOAD 5
#define DIGITS 2
// create shift register object (number of shift registers, data pin, clock pin, latch pin)
ShiftRegister74HC595 sr (DIGITS, SDI, SCLK, LOAD);


int value,digit1,digit2,digit3,digit4;
uint8_t  digits[] = {B11000000, //0
                      B11111001, //1
                      B10100100, //2
                      B10110000, //3
                      B10011001, //4
                      B10010010, //5
                      B10000010, //6
                      B11111000, //7
                      B10000000, //8
                      B10010000 //9
                     };

void setup() {



}

void loop() {
  showNumber(18);
  delay(2000);//
  for(int i=0; i<=99; i++)
  {
    showNumber(i);
    delay(100);
  }
  delay(2000);
  for(int i=99; i >=0; i--)
  {
    showNumber(i);
    delay(50);
  }
   delay(2000);
}// loop





/*
 * @brief shows number on the Seven Segment Display
 * @param "num" is an integer
 * @return returns none
 * Usage to show 18: showNumber(18);
 * Written by Ahmad Shamshiri on September 17, 2019.
 * in Ajax, Ontario, Canada
 * www.Robojax.com
 */
void showNumber(int num)
{
    digit2=num % 10 ;
    digit1=(num / 10) % 10 ;
    //Send them to 7 segment displays
    uint8_t numberToPrint[]= {digits[digit2],digits[digit1]};
    sr.setAll(numberToPrint);
}
