 * Arduino code to control AC bulb with relay
 *
 *
 * Written by Ahmad Shamshiri for Robojax.com on Saturday, August 17, 2019
 * at 16:27 in Ajax, Ontario, Canada
 * Watch video instructions
 * for this code: https://youtu.be/g6k8sPJyif8
 *
 * This code is "AS IS" without warranty or liability. Free to be used as long as you keep this note intact.
 * This code has been downloaded from Robojax.com
    This program is free software: you can redistribute it and/or modify
    it under the terms of the GNU General Public License as published by
    the Free Software Foundation, either version 3 of the License, or
    (at your option) any later version.

    This program is distributed in the hope that it will be useful,
    but WITHOUT ANY WARRANTY; without even the implied warranty of
    MERCHANTABILITY or FITNESS FOR A PARTICULAR PURPOSE.  See the
    GNU General Public License for more details.

    You should have received a copy of the GNU General Public License
    along with this program.  If not, see <https://www.gnu.org/licenses/>.
 */


int relayPin = 3;
int loopDelay = 1000;// delay in loop


void setup() {

    pinMode(relayPin, OUTPUT);// set pin as output
    digitalWrite(relayPin, HIGH); // set initial state OFF for low trigger relay



  Serial.begin(9600);// initialize serial monitor with 9600 baud
  Serial.println("Robojax Relay Control- AC bulb");
  delay(2000);
}

void loop() {
  // Robojax AC load control with 5V relay
 // turn relay ON
  digitalWrite(relayPin, LOW);
  Serial.println("Relay is ON");
  delay(2000);// wait for 2 seconds


 // turn relay OFF
  digitalWrite(relayPin, HIGH);
  Serial.println("Relay is OFF");
  delay(2000);// wait for 2 seconds


 Serial.println("===============");

 delay(loopDelay);// wait for loopDelay ms

}// loop end

++
/*
 * Arduino code to control AC bulb with a relay
 * This is advanced code which works with LOW trigger and HIGH trigger relays
 *
 * Written by Ahmad Shamshiri for Robojax.com on Saturday, August 17, 2019
 * at 16:27 in Ajax, Ontario, Canada
 * Watch video instructions
 * for this code: https://youtu.be/g6k8sPJyif8
 *
 * This code is "AS IS" without warranty or liability. Free to be used as long as you keep this note intact.
 * This code has been downloaded from Robojax.com
    This program is free software: you can redistribute it and/or modify
    it under the terms of the GNU General Public License as published by
    the Free Software Foundation, either version 3 of the License, or
    (at your option) any later version.

    This program is distributed in the hope that it will be useful,
    but WITHOUT ANY WARRANTY; without even the implied warranty of
    MERCHANTABILITY or FITNESS FOR A PARTICULAR PURPOSE.  See the
    GNU General Public License for more details.

    You should have received a copy of the GNU General Public License
    along with this program.  If not, see <https://www.gnu.org/licenses/>.
 */


int relayPin = 3;
const int triggerType = LOW;// your relay type
int loopDelay = 1000;// delay in loop

int relayOFF, relayON;// relay ON and OFF values for LOW and HIGH Trigger relays


void setup() {

    pinMode(relayPin, OUTPUT);// set pin as output
    if(triggerType ==LOW){
      relayON = LOW;
      relayOFF = HIGH;
      digitalWrite(relayPin, relayOFF); // set initial state OFF for low trigger relay
    }else{
      relayON = HIGH;
      relayOFF = LOW;
       digitalWrite(relayPin, relayOFF); // set initial state OFF for high trigger relay
    }


  Serial.begin(9600);// initialize serial monitor with 9600 baud
  Serial.println("Robojax Relay Control - Advanced code");
  delay(2000);
}

void loop() {

 // turn relay ON
  digitalWrite(relayPin, relayON);
  Serial.println("Relay is ON");
  delay(2000);// wait for 2 seconds


 // turn relay OFF
  digitalWrite(relayPin, relayOFF);
  Serial.println("Relay is OFF");
  delay(2000);// wait for 2 seconds


 Serial.println("===============");

 delay(loopDelay);// wait for loopDelay ms

}// loop end
