 * Display WiFi Access Point Signal Strength on LCD1602-I2C as dBm or Percentage with ESP8266 Arduino
 * Written by Ahmad Shamshiri on August 12, 2019
 * in Ajax, Ontario, Canada
 * for Robojax.com
 * Watch video instruction for this code: https://youtu.be/HYMnCUtNMnw
 *
Get this code and other Arduino codes from Robojax.com
Learn Arduino step by step in a structured course with all material, wiring diagrams, and libraries
all in one place.

If you found this tutorial helpful, please support me so I can continue creating
content like this.

or make a donation using PayPal http://robojax.com/L/?id=64

*/
#include "ESP8266WiFi.h"
const int RSSI_MAX =-50;// define maximum strength of signal in dBm
const int RSSI_MIN =-100;// define minimum strength of signal in dBm


// start of settings for LCD1602 with I2C
#include <LiquidCrystal_I2C.h>
// Set the LCD address to 0x27 for a 16 chars and 2 line display
LiquidCrystal_I2C lcd(0x3F, 16, 2);
// end of settings for LCD1602 with I2C

int count =0;

int scanDelayTime = 1000;
int wiFiDisplayTime = 3000;

void setup() {
  // Set WiFi to station mode and
  WiFi.mode(WIFI_STA);
  WiFi.disconnect();//disconnect from an AP if it was previously connected

  lcd.begin();
  lcd.backlight();
  lcd.print("Robojax ESP8266");
  lcd.setCursor(0,1);
  lcd.print("Wifi Scan Demo");
  delay(2000);
}


void loop() {
 // Robojax D1 Mini LCD-1602-I2C  WiFi Scan

// WiFi.scanNetworks will return the number of networks found
  int n = WiFi.scanNetworks();
  lcd.clear();// clear previous values from screen
  lcd.print("scan done");
  if (n == 0) {
    lcd.print("No WiFI found");
  } else {
    lcd.setCursor(0,1);
    lcd.print(n);
    lcd.print( " AP found");
    for (int i = 0; i < n; ++i) {

      // Print SSID and RSSI for each network found
      lcd.clear();// clear previous values from screen
      lcd.setCursor(0,0);
      lcd.print(i+1);
      lcd.print(") ");
      lcd.print(WiFi.SSID(i));
      lcd.setCursor(0,1);
      lcd.print("Signal: ");
      lcd.print(dBmtoPercentage(WiFi.RSSI(i)));
      lcd.print("%");
      delay(wiFiDisplayTime);
    }
  }

  delay(scanDelayTime);
}// loop end


/*
 * Written by Ahmad Shamshiri
  * with lots of research, these sources were used:
 * https://support.randomsolutions.nl/827069-Best-dBm-Values-for-Wifi
 * This is an approximate percentage calculation of RSSI
 * Wifi Signal Strength Calculation
 * Written August 8, 2019 at 21:45 in Ajax, Ontario, Canada
 */

int dBmtoPercentage(int dBm)
{
  int quality;
    if(dBm <= RSSI_MIN)
    {
        quality = 0;
    }
    else if(dBm >= RSSI_MAX)
    {
        quality = 100;
    }
    else
    {
        quality = 2 * (dBm + 100);
   }

     return quality;
}//dBmtoPercentage
