The HC-05 Bluetooth module (commonly found on AliExpress with a built‑in push button) is a versatile wireless serial communication device. It is designed to replace wired RS‑232 connections with short‑range Bluetooth, making it a favorite among hobbyists, engineers, and IoT developers. At its heart is the CSR BC417 chip (a BlueCore4‑External device) paired with a 2.4 GHz radio. The module can operate in two modes: master, slave, or loopback, configurable via AT commands. The push button simplifies entering AT command mode (hold it while powering on) or pairing with other devices. Using just a UART interface (TX/RX, VCC, GND), you can connect the HC‑05 to microcontrollers like Arduino, STM32, ESP32, or Raspberry Pi for wireless data exchange.

Typical applications include:

• Wireless robot / drone control (joystick + motor driver)
• Bluetooth‑based home automation (light, fan, relay switching)
• Wireless sensor data logging (temperature, humidity, GPS)
• Smartphone‑controlled LED strips or RGB matrix panels
• Bluetooth pass‑through for debugging embedded systems
• Wireless programmer for Arduino / STM32 (via Bluetooth SPP)
• Remote access to serial printers or medical devices

Key specifications:

• Chipset: CSR BC417 (Bluetooth 2.0+EDR, backward compatible)
• Operating voltage: 3.6 V – 6 V (onboard 3.3 V regulator, 5 V tolerant)
• Logic level: 3.3 V (5 V safe input via voltage divider)
• Default baud rate: 9600 bps (configurable up to 1382400 bps)
• Range: ≈10 meters (open air, Class 2)
• Push button function: Enter AT command mode / force pairing / reset stored devices
• Onboard LED indicators: Power (red) + connection status (blinking blue)
• Interface: 6 pins (EN, VCC, GND, TX, RX, STATE) – standard 0.1" pitch
• Default PIN for pairing: 1234 (can be changed via AT commands)
