FPV Transmitter and Receiver kit with 1km range.

Micro 5.8Ghz Video AV TX RX Combo System FPV 200mW 1km Range

This kit is perfect for any drone or RC car or DJI drone to send live video from the air to a ground station. You can connect it to a GoPro camera or one of the cameras we have here. With a 200mW transmitter, this transmitter can transmit video up to 1km in normal conditions.

RC305 Receiver

Features:
RC305 5.8G AV Receiver with 8 channels; it can receive high-quality video and audio signals.
With broadband receiving frequency: 5725-5865MHz.
Small size, lightweight, easy to carry.
Ideal for FPV, wireless remote-control aircraft, wireless remote-control vehicles, and so on.

Specifications:
Receiving frequency: 5725-5865MHz; 8 channels
Receiving sensitivity: -90dBm
Frequency control: built-in frequency and phase-lock loop
Double lines AV output: analog AV signal output
Antenna connector: SMA (Inside the needle)
Power supply voltage: 6.5-12V
Supply current: 150mA

Frequency of each channel:
CH1:5705 - CH2:5685 - CH3:5665 - CH4:5645
CH5:5885 - CH6:5905 - CH7:5925 - CH8:5945

Applications: Remote-control aircraft / Remote spacecraft / Remote-control toys
Item size: 6.1 * 5.2 * 1.3cm / 2.4 * 2.0 * 0.5in
Item weight: 53g / 1.9oz (with antenna)
Package size: 15.5 * 10.6 * 3.7cm / 6.2 * 4.2 * 1.5in
Package weight: 110g / 3.8oz

TS351 Transmitter

5.8G 200mW AV wireless receiver and transmitter TS351

Features of 5.8G 200mW AV wireless receiver and transmitter:
5.8G 8ch transmitter
With channel DIN-switch to change channels

Specifications of 5.8G 200mW AV wireless receiver and transmitter:
Transmitter frequency:5705-5945MHz;8CH
Transmitting Power:200mW/23dBm
Transmitting distance:>2000m(open area)
AV input:analog AV signal input
power supply:6.5-15 volts
Current supply:200mA
Weight: 30g
Size:55*26*17mm
Remark:The transmitter's power input ranges from 7-12V; however, the voltage output from the TX for the camera is 0.5V, lower than the input power. It is suggested to use a 3S lipo 11.1V battery.
Note: Antennas must be attached before powering on.

Default: Antenna connector:SMA(Inside the needle)

Frequency of each channel:
CH1:5705 - CH2:5685 - CH3:5665 - CH4:5645
CH5:5885 - CH6:5905 - CH7:5925 - CH8:5945

2-pin connector:
Red: DC8-12 Volts Input
Black: GND

5-pin connector:
Red: V output for your camera, normally 0.5V less than the DC input from the 2-pin connector.
Black:GND
Yellow: VIDEO
