* S08-01
* Lesson 69: Proximity Sensor E18-D80NK with Arduino
 * This is the Arduino code for E18-D80NK Infrared Obstacle Avoidance Sensor.
This code is to use E18-D80NK Infrared Sensor to detect obstacles and trigger an
event like starting or stopping a motor, servo, relay, or anything else.
  Watch instruction video for this code: https://youtu.be/bu0LHgXq7Pw

 *  *
 // Written by Ahmad Shamshiri for Robojax.com on
// February 22, 2018 at 20:50 in Ajax, Ontario, Canada

 * Disclaimer: this code is "AS IS" and for individual educational purposes only.
 *

  This video is part of Arduino Step by Step Course which starts here: https://youtu.be/-6qSrDUA5a8



If you found this tutorial helpful, please support me so I can continue creating
content like this.

or make a donation using PayPal http://robojax.com/L/?id=64

 * This code is "AS IS" without warranty or liability. Free to be used as long as you keep this note intact.*
 * This code has been downloaded from Robojax.com
    This program is free software: you can redistribute it and/or modify
    it under the terms of the GNU General Public License as published by
    the Free Software Foundation, either version 3 of the License, or
    (at your option) any later version.

    This program is distributed in the hope that it will be useful,
    but WITHOUT ANY WARRANTY; without even the implied warranty of
    MERCHANTABILITY or FITNESS FOR A PARTICULAR PURPOSE.  See the
    GNU General Public License for more details.

    You should have received a copy of the GNU General Public License
    along with this program.  If not, see <https://www.gnu.org/licenses/>.
The wiring:
Brown: 5V DC
Blue: GND
Black: Signal, to PIN 2




 *

*/
#define SENSOR 2 // define pint 2 for sensor
#define ACTION 9 // define pin 9 as for ACTION

/*
 * Permission granted to share this code given that this
 * note is kept with the code.
 * Disclaimer: this code is "AS IS" and for educational purposes only.
 *
 */

void setup() {
  // E18-D80NK Obstacle Sensor Code by Robojax.com 2018022
  Serial.begin(9600);// setup Serial Monitor to display information
  pinMode(SENSOR, INPUT_PULLUP);// define pin as Input  sensor
  pinMode(ACTION, OUTPUT);// define pin as OUTPUT for ACTION
}

void loop() {
  // E18-D80NK Obstacle Sensor Code by Robojax.com 2018022
  int L =digitalRead(SENSOR);// read the sensor

      if(L == LOW){
        Serial.println(" Obstacle detected");
        digitalWrite(ACTION,HIGH);// send signal

     }else{

        Serial.println("  === All clear");
        digitalWrite(ACTION,LOW);// turn the relay OFF
     }
  delay(500);
 // E18-D80NK Obstacle Sensor Code by Robojax.com 2018022
}
