How to Use Continuous 360° Servo with Arduino

In this tutorial, we will learn how to control a continuous 360° servo using an Arduino. Unlike standard servos, continuous servos can rotate indefinitely in either direction, allowing for versatile applications. However, controlling their position requires understanding the commands sent to them and a bit of experimentation to find the right stopping values.

We will be developing a program that allows us to send commands via the Serial Monitor to rotate the servo left, right, or stop it. The code will include the necessary logic to interpret the ASCII values of the commands we enter. For clarification on the coding process, be sure to check the video at (in video at 12:30).

Hardware Explained

To implement this project, you will need a continuous 360° servo, an Arduino board, and a power supply capable of providing sufficient current (at least 500mA). The servo receives control signals from the Arduino, which uses pulse width modulation (PWM) to dictate the direction and speed of rotation.

The servo motor itself has three wires: power, ground, and control. The power wire connects to the power supply, the ground wire connects to both the power supply and the Arduino ground, and the control wire connects to a designated pin on the Arduino for signal transmission.

Datasheet Details

• Ensure a common ground between the Arduino and power supply.
• Use an external power supply for the servo to avoid overloading the Arduino.
• Experiment with stopping values to find the best performance for your servo.
• Monitor the servo temperature during operation to prevent overheating.
• Use a PWM signal to control the speed and direction of the servo.

Wiring Instructions

To wire your continuous 360° servo to the Arduino, start by connecting the servo power wire to an external power supply that provides 5V. The ground wire of the servo should be connected to the ground (GND) pin on the Arduino, ensuring that the power supply and Arduino share a common ground. The control wire of the servo will go to pin 9 on the Arduino, which is where the PWM signal will be sent from.

Double-check that your connections are secure, as loose connections can lead to erratic servo behavior. If your servo is of a type that can be powered directly from the Arduino, you may connect the power wire to the Arduino's 5V pin, but ensure the total current does not exceed what the Arduino can supply.

Code Examples & Walkthrough

The following excerpt demonstrates how to set up the servo and read commands from the Serial Monitor:

#include

Servo myservo;  // create servo object to control a servo
int incomingByte = 0;   // for incoming serial data

void setup() {
  Serial.begin(9600);
  myservo.attach(9);  // attaches the servo on pin 9 to the servo object
}

In this code snippet, we include the Servo library and create a servo object called myservo. We also set up the serial communication at 9600 baud and attach the servo to pin 9.

Next, we have the main loop where we read incoming serial data and control the servo based on the commands:

void loop() {
  if (Serial.available() > 0) {
    incomingByte = Serial.read();
    if (incomingByte == 108) { // 'L' command
      myservo.write(0); // rotate clockwise
    } else if (incomingByte == 114) { // 'R' command
      myservo.write(180); // rotate counterclockwise
    } else if (incomingByte == 60) { // stop command
      myservo.write(60); // stop servo
    }
  }
}

This code checks if there is any data available in the serial buffer. Depending on the ASCII value of the input (e.g., 108 for 'L' to rotate clockwise, 114 for 'R' to rotate counterclockwise), it sends the corresponding command to the servo.

For complete code and additional details, please refer to the full program loaded below the article.

Demonstration / What to Expect

When you upload the code and open the Serial Monitor, you can enter 'L' to rotate the servo left, 'R' to rotate it right, or other values to experiment with stopping the servo. Expect to find various stopping values, as the servo's behavior may vary based on its quality and design (in video at 18:45).

Be cautious of how the servo reacts to the commands; if it does not stop as expected, try different values until you find the optimal stopping command. This may require some experimentation, especially to avoid overheating the servo.
