Digital clock AT89C2051 DIY Electronics Kit step by step Assembly
This project guide details the step-by-step assembly of a digital clock kit based on the AT89C2051 microcontroller (also known as C51). This compact and versatile microcontroller is perfect for a variety of DIY projects. Building this clock provides a hands-on learning experience in electronics assembly and basic microcontroller programming. The completed clock offers practical applications such as:
- A simple, reliable timekeeping device for workshops or bedrooms.
- A teaching tool for electronics and microcontroller programming.
- A base for more complex projects involving time-based control.
Hardware/Components
The kit includes the following components (in video at 01:21):
- AT89C2051 Microcontroller
- Two 10kΩ resistors
- Two 30pF capacitors
- One 100nF capacitor
- One 10µF electrolytic capacitor
- One 1kΩ resistor array (8 resistors + 1 common pin)
- 12MHz crystal oscillator
- 8550 transistor
- Two push-button switches
- 20-pin IC socket
- 5V buzzer/speaker
- Seven-segment display module
- Two-pin terminal block
- 52x42mm PCB
A detailed schematic diagram is available for download at robojax.com (in video at 00:43).
Wiring Guide
The wiring process is extensively illustrated in the video. The schematic diagram (in video at 04:38) shows the connections between the components. A voltage divider is not explicitly used in this project; the resistors are primarily used to limit current to the seven-segment display. The multiplexing technique is used to reduce the number of wires needed to drive the seven-segment display (in video at 05:56). The 12MHz crystal provides the clock signal, which is then divided down to 1Hz by the microcontroller (in video at 06:53).
Live Project/Demonstration
The video demonstrates the assembly process (in video at 07:28) and the functionality of the completed clock (in video at 21:08). The clock is powered by a 5V supply (in video at 21:08). Two buttons are used to set the time and activate the alarm functions (in video at 22:47). The video also shows how to set the two alarms (in video at 23:14).
Chapters
- [00:06] Introduction and Project Overview
- [01:21] Components List
- [04:38] Schematic Diagram Explanation
- [07:28] Soldering the Components (Resistors and Capacitors)
- [15:17] Soldering Switches and Buzzer
- [17:18] Soldering IC Socket and Power Terminal
- [19:42] Soldering Seven-Segment Display and Microcontroller
- [21:08] Powering Up and Testing the Clock
- [22:47] Setting the Time and Alarms
- [26:01] Alternative Powering Options
