In this tutorial, we will build a Tesla coil that can illuminate lights without any direct connection. The outcome will be a functional Tesla coil that can respond to audio signals, creating visible sparks and lighting effects. This project involves soldering components and testing their connections to ensure everything works properly. For further clarification, be sure to check out the video at the specified timestamps.

Hardware Explained

The primary components used in this Tesla coil kit include a MOSFET, resistors, LEDs, a capacitor, and an audio jack. The MOSFET acts as a switch that controls the high voltage output, allowing the coil to generate oscillations. The resistors are used for biasing, ensuring that the MOSFET operates correctly. LEDs provide visual feedback, indicating when the circuit is active.

Additionally, the capacitor plays a crucial role in the oscillation process, working alongside the inductor to create the necessary conditions for high voltage generation. The audio jack connects to an audio source, modulating the oscillations based on the music's beats, which allows the Tesla coil to produce sparks in response to sound.

Datasheet Details

Manufacturer	Generic
Part number	MOSFET (e.g., IRF520)
Logic/IO voltage	4.5 – 20 V
Supply voltage	15 – 24 V
Output current (per channel)	9.2 A max
Peak current (per channel)	30 A max
PWM frequency guidance	10 kHz typical
Input logic thresholds	2 – 4 V (low), 10 V (high)
Voltage drop / R_DS(on) / saturation	0.27 Ω (typ.)
Thermal limits	175 °C max
Package	TO-220
Notes / variants	Commonly used in switching applications

Kit components:

Tesla Coil Kit: Main Kit — Tesla Coil Kit: main kit

Ensure proper heat sinking for the MOSFET to avoid overheating.
Use decoupling capacitors close to the power pins to stabilize voltage.
Check the polarity of the electrolytic capacitor before soldering.
Be cautious with the audio jack; ensure it is securely connected.
Double-check all connections before powering the circuit.
Use appropriate resistors to prevent excessive current through LEDs.
Make sure the coil is positioned correctly to induce high voltage.

Tesla Coil Kit: 1-turn coil wire (red or black) — Tesla Coil Kit: 1 turn coil wire (red or black)

Tesla Coil Kit: PCB

Tesla Coil Kit: 1 turn coil wire (red or black)

Tesla Coil Kit: PCB

Demonstration / What to Expect

When properly assembled, the Tesla coil should produce visible sparks and light up LEDs in response to audio signals. You can expect the lights to flicker in sync with the beats of the music played through the connected audio jack (in video at 12:45). If the device does not operate as expected, check for loose connections or incorrect component placements, especially around the MOSFET and audio input.
