Lesson 109-5: Setting Output Voltage with a Push Button Using an MCP4725 DAC with Arduino
In this lesson, we learn how to use the MCP4725 12-bit digital-to-analog converter (DAC). The chip and module are explained, the datasheet is reviewed, and then, using five projects, this MCP4725 is practically shown. Full wiring diagrams are shown, and how to use the code and library is explained.
Project 5 in lesson 109, Lesson 109-5: Controlling the speed of a motor using a variable resistor (potentiometer) and a start/stop push button with Arduino.
383-Lesson 109: Generating DC Voltage Using an MCP4725 DAC with LCD and PWM-to-Voltage Converter with Arduino (5 Projects)
Language: C++
