Review of a 400W DC Step-Up Boost Converter: 8.5V-50V Input to 10V-60V Output

The module is fully explained, including its components. Minimum and maximum input and output voltages were tested. Setting the current limit is shown and tested with inputs and outputs of 9 V, 12 V, 15 V, 24 V, and 36 V at different currents so we know how much current it can produce. A thermal image shows the module's hottest spot. Links to resources and purchasing options for this module are below.
