DSO138 Digital Oscilloscope Kit: How to Use It
In this tutorial, we learn how to use the DSO138 digital oscilloscope kit. These are its features. If you want to learn how to assemble it, please watch this tutorial.
If you want to learn how to do the acrylic case assembly, please see this tutorial.
You don't need a signal generator to test the oscilloscope. There is a test point with a 1kHz square wave signal on the scope; test and view the signal. See the image here.
الصور
DSO138 digital oscilloscope: Main view
DSO138 digital oscilloscope: Connected to power
DSO138 digital oscilloscope: View from upper side
DSO138 digital oscilloscope: Square wave displayed
DSO138 digital oscilloscope: with signal cable
DSO138 digital oscilloscope: Test signal point
DSO138 Test Point
